LOGSET SERIES

LOGSET SERIES

ELECTRIC FIREPLACES > INSERT SERIES

 •Insert series electric fireplaces keep your home warmer, increase efficiency, and reduce the amount of wasted energy.


 •Traditional looks bring homey style to the home. It is best choice if your prefer traditonal looks fireplace

DIMENSIONS



ArcFlame Key Features
Insert series electirc fireplaecs
Front venting fullly recess
All season usage: flames operate with or without heat output
Main Dimensions
Depth with front glass9.33"
Back Firebox width26.83"
Back Firebox depth9.05"
Back Firebox height20.74"
Front Width30"
Front Height21.81"
Ember bed depth3.82"
View area width25.98"
View area height17"

lux dimensions.png


PRODUCT DIMENSIONS
Model#ABCDEFG
LIF30BTFV30''21.73''9.28''21.73''26.14'''17''25.98''

LIF30BTFV(LUX30) with final manual   2022_Page_1.png


Fireplace Type:

Front-View
Available Models:30"
Depth:

9.33” including the front glass

9.05” firebox


SPECIFICATIONS

30LUXinfor2 web 2023APR03.png

30LUXinfor1 web 2023APR03.png


Technical Specification

Product Finish

Black

Wattage

1500W

Voltage

120V

BTU

5000

Product Depth/Lenth(in)

9.33

Product Height(in)

21.81

Product Weight

26KGS

Timer

1

Remote Control

Yes

Built-in Thermostat

Yes

Automatic Shut-off

Yes

Power Souce

Electric

INSTALLATION


LIF30BTFV(LUX30) with final manual   2022_Page_3 - Copy.png

LIF30BTFV(LUX30) with final manual   2022_Page_3.png

 Easy to installation :

 Insert only product

INSTALLATION
YESInsert
NOWall hanging
YESBuilt in Clean face


ELECTRICAL
Heater1500W/5000BTU

Up to 10,000BTU's &3,000 Watts
Heater wire optionYes
Plug inYes











NOTE:

Select a location that is not prone to moisture and is located at least 36" (91.4cm) away from combustible materials such as curtain drapes, furniture, bedding, paper, etc.











INSTALLATION DIMENSIONS
Model# HIJKLM
LIF30BTFV  27.725''   21.5''  9.25''  44.25''   31.375''    31.375''





30lux infor new - Copy.png






30lux infor new - Copy (3).png





30lux infor new - Copy (4).png
