ELECTRIC FIREPLACES > LINEAR SERIES
•Top venting electric fireplaces keep your home warmer, increase efficiency, and reduce the amount of wasted energy.
•Total is two venting holes, the top one is the air outlet for heating other for the air inlet.
•There is 3 color model for your option, black color brings a sense of elegant style to your space; white color is easy to match with your light color furniture; red color can quickly catch people’s eyes
Key Features | |
Ultra slim 4" depth front venting linear electirc fireplaecs | |
Front venting fullly recess | |
All season usage: flames operate with or without heat output | |
Main Dimensions | |
Depth with front glass | 4.2" |
Back Firebox depth | 4" |
Front Width | 36"/42"/50"/60"/72"/84" |
Front Height | 20" for 36", 42", 50" and 60" |
23 1/4" for 72" and 84" | |
Ember bed depth | 3/4" |
View area height | 9 1/4 " for 36" ,42" , 50" and 60" |
10" for 72" and 84" |
PRODUCT DIMENSIONS | |||||||
Model# | A | B | C | D | E | F | G |
SS36FV3FBL | 36'' | 20'' | 4.2'' | 18.8'' | 30.10''' | 9.72'' | 26'' |
SS42FV3FBL | 42'' | 20'' | 4.2'' | 18.8'' | 36.10'' | 9.72'' | 31.97'' |
SS50FV3FBL | 50'' | 20'' | 4.2'' | 18.8'' | 44.10'' | 9.72'' | 39.72'' |
SS60FV3FBL | 60'' | 20'' | 4.2'' | 18.8'' | 54.10'' | 9.72'' | 50'' |
SS72FV3FBL | 72'' | 23.25'' | 4.2'' | 20.27'' | 66.10'' | 10.24'' | 60'' |
SS84FV3FBL | 84'' | 23.25'' | 4.2'' | 20.27'' | 77.10'' | 10.24'' | 72'' |
Fireplace Type: | Front-View |
Available Models: | 36, 42, 50, 60, 72, 84 |
Depth: | 4.2” including the front glass 4” firebox |
Technical Specification | |
Product Finish | Black |
Wattage | 1400W |
Voltage | 120V |
BTU | 4777 |
Product Depth/Lenth(in) | 5 |
Product Height(in) | 19.5 |
Product Weight(in) | 104.12 |
Timer | 1 |
Remote Control | Yes |
Built-in Thermostat | Yes |
Automatic Shut-off | Yes |
Power Souce | Electric |
Easy-to-use builder's brackets provided for 3 install options:
1.Wall Mounted: Use with backlights
2.Partial Recess:1"gap for flexible use
3.Full Recess:Flush to wall
INSTALLATION | |
YES | Recess Wall Mount only 0.2' from the wall |
YES | Wall hanging |
Built in Clean face |
ELECTRICAL | |
Heater | |
1500W/5000BTU | |
Up to 10,000BTU's &3,000 Watts | |
Heater wire option | |
Yes | |
Plug in | |
Yes |
Easy-to-use builder's brackets provided for 3 install options:
1. Wall Mounted: Use with backlights
2.Partial Recess:1"gap for flexible use
3.Full Recess:Flush to wall
Item# | A | B |
SS36FV3f8L | 19.3'' | 32.60'' |
SS42FV3f8L | 19.3'' | 38.60'' |
SS50FV3f8L | 19.3'' | 46.60'' |
SS60FV3f8L | 19.3'' | 56.60'' |
SS72FV3f8L | 21.27'' | 68.60'' |
SS84FV3f8L | 21.27'' | 79.60'' |
